Sand washing and dewatering machine is a type of equipment for sand and gravel cleaning and dewatering, integrating sand washing and dewatering functions, improving the efficiency and quality of sand and gravel processing, which is widely used in sand and gravel plants, concrete mixing stations, construction sites and other fields.
01Feeding: Gravel enters the equipment through the feed inlet.
02Cleaning: In the cleaning tank, the gravel is in full contact with the water flow, and the impurities are separated.
03Dewatering: The cleaned gravel enters into the dewatering screen, and the water is removed by vibration and centrifugal force.
Sand washing and dewatering are performed at the same time to improve efficiency.
Water resources are recycled, reducing energy consumption.
Reduce wastewater discharge, meeting environmental protection standards.
Small footprint, easy to install and maintain.
1.Construction industry:used for removing soil and impurities, improving the purity of sand and gravel materials.
2.Mining industry:used to wash sand and gravel materials after crushing various ores.
3.Water conservancy and hydropower engineering:used to wash sand and gravel aggregate to meet the requirements of high-strength and high-durability materials in dams, hydroelectric power stations and other projects.
4. Highway and railway construction:used to clean roadbed and pavement materials.
5.Glass industry:used to clean quartz sand and produce high purity sand and gravel materials required for glass manufacturing.
6.Chemical Industry:used to clean chemical raw materials and produce gravel materials for chemical products.
|
Model |
Power （kw） |
Feed Particle Size（mm） |
Sand Output（m3/h） |
Overall Dimension （mm） |
|
XT1224 |
25.5 |
≤10 |
30-50 |
5900*2000*2600 |
|
XT1530 |
35.5 |
≤10 |
50-120 |
7000*2200*3000 |
|
XT1840 |
52.4 |
≤10 |
120-180 |
8000*2800*3500 |
