The linear contact of steel rods makes the material grinding more uniform, with less over-crushing.
Rod mill is especially suitable for coarse grinding operation and can also be used for fine grinding.
Suitable for both wet and dry grinding processes.
Stable operation and easy maintenance.
1. Mining industry: used for coarse and fine grinding of gold, copper, iron and other ores.
2. Building materials industry: used for grinding cement, ceramics and other raw materials.
3. Chemical industry: used for crushing chemical raw materials.
| Model | Cylinder Specification（mm） | Cylinder Speed （r/min.） |
Rod Charge (T) |
Feed Particle Size （mm） |
Discharge Particle Size （mm） |
Production Capacity (t/h) |
Motor Power （kw） |
Weight (T) |
|
| Diameter | Length | ||||||||
| MB0918 | 900 | 1800 | 29-31.3 | 2.3 | ≤25 | 0.16-5 | 1.6-6 | 22 | 4.8 |
| MB0924 | 900 | 2400 | 29-35.4 | 3.1 | ≤25 | 0.16-5 | 2.9-10 | 30 | 5.3 |
| MB1224 | 1200 | 2400 | 27-34 | 6.5 | ≤25 | 0.16-5 | 5.0-13 | 37 | 11.8 |
| MB1530 | 1500 | 3000 | 26.5-29.5 | 11.5 | ≤25 | 0.16-5 | 6.0-25 | 75 | 17.2 |
| MB1545 | 1500 | 4500 | 26.5-29.5 | 14 | ≤25 | 0.16-5 | 10-35 | 90 | 22 |
| MB1830 | 1800 | 3000 | 21.6-22.8 | 17.5 | ≤25 | 0.16-5 | 12-40 | 155 | 29.5 |
| MB1855 | 1800 | 5500 | 21.6-22.8 | 23 | ≤25 | 0.16-5 | 12-60 | 185 | 33 |
| MB2130 | 2100 | 3000 | 19-21 | 23.2 | ≤25 | 0.16-5 | 20-80 | 210 | 37 |
| MB2155 | 2100 | 5500 | 19-21 | 26 | ≤25 | 0.16-5 | 25-100 | 280 | 45 |
| MB2430 | 2400 | 3000 | 18-20 | 32 | ≤25 | 0.16-5 | 30-130 | 280 | 60 |
| MB2455 | 2400 | 5500 | 18-20 | 46 | ≤25 | 0.16-5 | 50-180 | 380 | 79 |
| MB2755 | 2700 | 5500 | 17.2-18.5 | 51 | ≤25 | 0.16-5 | 80-250 | 560 | 112 |
| MB3055 | 3000 | 5500 | 17-18 | 62 | ≤25 | 0.16-5 | 120-300 | 630 | 123 |
| MB3255 | 3200 | 5500 | 16.5-18 | 70 | ≤25 | 0.16-5 | 150-380 | 800 | 138 |
| MB3660 | 3600 | 6000 | 16-18 | 93 | ≤25 | 0.16-5 | 200-580 | 1600 | 210 |
